| Amp Ratings |
Three Phase HP Ratings |
||||||
|---|---|---|---|---|---|---|---|
| AC3 | AC1 | 230V | 460V | Screw Terminals | Spring Loaded Terminals | ||
 3RT2035-1AC20 |
40 | 60 | 15 | 30 | 3RT2035-1A..0 | 3RT2035-3A..0 | |
| 24V 3RT2035-1AC20 | 3RT2035-3AC20 | ||||||
| 120V 3RT2035-1AK60 | 3RT2035-3AK60 | ||||||
| 240V 3RT2035-1AP60 | 3RT2035-3AP60 | ||||||
| 3RT2036-1A..0 | 3RT2036-3A..0 | ||||||
| 50 | 70 | 15 | 40 | 24V 3RT2036-1AC20 | 3RT2036-3AC20 | ||
| 120V 3RT2036-1AK60 | 3RT2036-3AK60 | ||||||
| 240V 3RT2036-1AP60 | 3RT2036-3AP60 | ||||||
 3RT2037-1AC20 |
65 | 80 | 20 | 50 | 3RT2037-1A..0 | 3RT2037-3A..0 | |
| 24V 3RT2037-1AC20 | 3RT2037-3AC20 | ||||||
| 120V 3RT2037-1AK60 | 3RT2037-3AK60 | ||||||
| 240V 3RT2037-1AP60 | 3RT2037-3AP60 | ||||||
| 3RT2038-1A..0 | 3RT2038-3A..0 | ||||||
| 80 | 90 | 25 | 50 | 24V 3RT2038-1AC20 | 3RT2038-3AC20 | ||
| 120V 3RT2038-1AK60 | 3RT2038-3AK60 | ||||||
| 240V 3RT2038-1AP60 | 3RT2038-3AP60 | ||||||
